GW Brushless 48K 480 Long Shaft 11.1v AEG Gel Blaster Motor

GreyWolf Brushless 48,000 480 Long Shaft 11.1v AEG Gel Blaster Motor

Upgrade your gel blaster with the GreyWolf Brushless 48,000 480 Long Shaft 11.1v AEG Gel Blaster Motor for unmatched performance and reliability. Featuring a state-of-the-art brushless motor, this upgrade delivers increased efficiency, higher torque-to-weight ratios, and exceptional power input. The integrated MOSFET unit offers unparalleled control and extremely fast reaction times, ensuring your gel blaster operates at peak performance. With a direct plug-in installation, you can easily enhance your gear without the need for modifications or additional wiring.

Please Note: Installation of an upgraded motor is a technical process and should be conducted by an experienced Gel Blaster Technician. Also, with this upgrade, the gear box should ideally have a full re-build and potentially requires upgraded components to ensure that the gears, bearings, shims and all components are capable of handling the increase in power and overall RPMs. Every gearbox adjustment, must include a re-shim to ensure smooth operation and reduce the risk of damage.

The GreyWolf Brushless Motor is equipped with advanced protective features, including voltage protection below 5.5V and above 13.5V, battery low voltage protection for 2CELL (below 6V) and 3CELL (below 9V), and temperature protection up to 100 degrees Celsius. Stall protection ensures the motor’s longevity, even if gear damage or other issues arise. Enjoy a quieter, more efficient operation with reduced mechanical noise and near-elimination of electromagnetic interference (EMI). The brushless design also eliminates ionizing sparks from the commutator, providing a longer lifespan and reducing maintenance requirements. Upgrade today for a more reliable and powerful gel blaster experience!

GW Brushless 48K 480 Long Shaft 11.1v AEG Gel Blaster Motor Features:

• Wide speed regulation: adjustable range 39000~48000RPM11.1VDC
• Small no-load loss:48000RPM, no-load current ≤3.7A (4.2A); 39000RPM, no load current ≤3.0A (2.7A)
• 7075 Aluminium high quality casing
• Total custom in-runner design with maximum power and torque
• High temperature resistant quality copper windings
• High Speed.
• High Torque.
• High quality Nd-Fe-B magnets
• Internal ESC with over amp draw and low voltage cut off to protect the motor and battery.
• High Precision CNC design
• High quality D-cut removable pinion gear for easy switch outs

RPM:

• 31,000 with 8.4v
• 48,000 with 11.1v (with no load)

GW Brushless 48K 480 Long Shaft 11.1v AEG Gel Blaster Motor Specifications:

• Package Weight: 193 g
• Package Dimensions: 9.6 x 6.1 x 3 cm
• Motor Weight: 134 g
• Type: AEG 480 Long Shaft Motor

Note: Do not exceed an M130 size spring.

Special Note: Installation at home of upgraded components, will void any warranty that is still valid on your blaster. If in doubt, seek advice from our Technicians, and request an estimate on having us conduct the work and upgrades for you. Damage caused to your pride and joy, cannot be “un-done”, so it is best to check things out before making any changes to the stock Gel Blaster.
